ResMed AirCurve 11 VAuto BiPAP with HumidAir

ResMed AirCurve 11 BiPAP with HumidAir Humidifier (Models 39018 and 39019)

The AirCurve 11 BiPAP is ResMed's latest offering in bilevel therapy, building upon the success of its predecessor, the AirCurve 10. This device is engineered to deliver two distinct pressure levels - a higher pressure for inhalation (IPAP) and a lower pressure for exhalation (EPAP) - making it easier for patients to breathe naturally throughout the night. The AirCurve 11 combines advanced algorithms, user-friendly features, and integrated humidification to ensure optimal therapy and patient comfort.

Product Highlights

• Advanced Bilevel Technology: The AirCurve 11 adjusts both inhalation and exhalation pressures automatically with VAuto Mode, ensuring real-time therapy adjustments based on your breathing patterns.
• Easy-Breathe Waveform: Mimics natural breathing patterns, offering a more comfortable and synchronized therapy experience.
• VSync Leak Compensation: Automatically compensates for mask leaks to maintain consistent pressure delivery.
• TiControl Customization: Allows healthcare providers to set specific inspiratory time limits for tailored therapy.
• Integrated Humidification: Built-in heated humidifier reduces dryness and nasal congestion for improved comfort.
• User-Friendly Interface: Features a color LED touchscreen, large on/off button, and an intuitive menu for easy navigation.
• Versatile Therapy Modes: Includes VAuto, S, and CPAP modes, with Expiratory Pressure Relief (EPR) for easier exhalation.
• Connectivity & Portability: Offers built-in cellular and Bluetooth connectivity, weighs under 3 pounds, and is FAA-approved for travel

Comparing ResMed AirCurve 11 with AirCurve 10

Here’s a comparison of the ResMed AirCurve 11 VAuto BiPAP with HumidAir and the ResMed AirCurve 10 VAuto BiLevel Machine with HumidAir:

Technical Specifications

• Dimensions: 10.21" L x 5.45" W x 3.72" H (device only)
• Weight: 2.7 lbs (device with humidifier)
• Noise Level: 27 dBA (±2 dBA)
• Pressure Range: 3 to 25 cm H2O
• Humidifier Capacity: 380 mL
• Power Supply: Universal AC power 100-240V, 50-60Hz (Auto Sensing)
• Data Storage: On-board memory and cloud-based storage via cellular connection

myAir App Integration

The AirCurve 11 seamlessly integrates with ResMed's myAir app, offering patients:

• Daily sleep scores and therapy progress tracking
• Personalized coaching and encouragement
• Video tutorials and setup guides
• Troubleshooting assistance for common CPAP issues

Cleaning and Maintenance

To ensure optimal performance and hygiene, the AirCurve 11 requires regular cleaning:

1. Wash components with mild soap and warm water (max 131°F/55°C)
2. Rinse thoroughly
3. Air dry away from direct sunlight

The device features a removable water tub and disposable air filter for easy cleaning and replacement. For added convenience, an optional dishwasher-safe AirSense/AirCurve 11 Cleanable Water Tub is available.

Accessories and Compatibility

The AirCurve 11 is compatible with a wide range of accessories:

• ClimateLineAir 11 Heated Tubing
• Standard and slim non-heated tubing options
• Various mask types (full face, nasal, nasal pillows)
• Optional Air11 Side Cover for use without humidification
• Oximeter Model 3150 with BLE (sold separately) for SpO2 monitoring

Therapy Modes in Detail

VAuto Mode

The VAuto mode is the cornerstone of the AirCurve 11's adaptive therapy. It combines several advanced features to provide optimal treatment:

1. Automatic Pressure Adjustment: Continuously monitors breathing patterns and adjusts IPAP and EPAP pressures to maintain airway patency.
2. Flow Limitation Response: Detects subtle changes in airflow and increases pressure to prevent upper airway collapse.
3. Apnea Detection: Distinguishes between obstructive and central apneas, adjusting therapy accordingly.
4. Snore Detection: Responds to snoring events by increasing pressure to maintain an open airway.

S Mode (Spontaneous)

In S mode, the device allows healthcare providers to set fixed IPAP and EPAP pressures. This mode is beneficial for patients who require consistent pressure support throughout the night.

CPAP Mode

For patients who may not require bilevel therapy, the AirCurve 11 offers a standard CPAP mode with the added benefit of Expiratory Pressure Relief (EPR) for enhanced comfort during exhalation.

Climate Control Technology

The Climate Control feature of the AirCurve 11, when used with the ClimateLineAir 11 Heated Tubing, offers advanced humidity management:

• Auto Mode: Automatically adjusts humidity and temperature based on ambient conditions and patient preferences.
• Manual Mode: Allows patients to set their preferred humidity and temperature levels.
• Rainout Prevention: Maintains optimal humidity levels while minimizing condensation in the tubing.

The ResMed AirCurve 11 BiPAP with HumidAir Humidifier represents a significant advancement in bilevel therapy technology. Its combination of adaptive pressure support, integrated humidification, user-friendly interface, and advanced connectivity options makes it a top choice for patients requiring bilevel therapy. Whether used for managing obstructive sleep apnea, central sleep apnea, or complex sleep apnea syndrome, the AirCurve 11 offers unparalleled comfort and efficacy, helping patients achieve better sleep and improved overall health.
